AIDimming 40W 50VDC 1000mA DALI Dimming LED Driver PE-L40DA42
Sale!
Original price was: ₹2,100.00.₹1,900.00Current price is: ₹1,900.00.
AiDimming 40W DALI-2 & Push Dimmable LED Driver (PE-L40DA42) | Constant Current 850mA–1000mA | Flicker-Free Professional Grade
Quick Summary
-
Dual Protocol: Full support for DALI-2 (Digital Addressable Lighting Interface) and Push Dim (Manual retractive switch control).
-
High Power Output: Up to 40W capacity, perfect for high-output downlights and COB fixtures.
-
Selectable Current: Integrated DIP switches allow you to choose between 850mA, 900mA, 950mA, or 1000mA.
-
Visual Comfort: Certified Flicker-Free (IEEE 1789 standard), eliminating eye strain and video flickering.
-
Smart Memory: Remembers your last brightness setting even after a power outage.
Description
| Specification | Details |
| Model | PE-L40DA42 |
| Input Voltage | 200–250V AC |
| Output Voltage Range | 25V – 42V DC |
| Max Output Power | 42W |
| Adjustable Current | 850mA / 900mA / 950mA / 1000mA |
| Dimming Range | 0% – 100% (Starts as low as 0.1%) |
| Power Factor | PF > 0.95 (High Efficiency) |
| Protection | Short Circuit, Over-Voltage, Over-Current, Over-Heat |
| Dimensions | 154.5 x 41 x 25 mm |
| Certifications | DALI-2, CE, RoHS, Class II |
